AXTON ATC200 slim

The ATC200S can easily replace the factory-installed components: the woofers can be swapped 1:1, and there is no need to install a common crossover for the mid/woofer and tweeter. A crossover is located directly on the woofer, which is included in the scope of delivery and has a compact 6 dB/oct. Tweeter crossover (with 0/-3 dB level reduction) can be conveniently placed behind the panel.

KEY FEATURES
– Bass/midrange driver with strontium ferrite magnet, polypropylene injection-molded membrane, NBR nitrile rubber surround, centering spider made of Nomex, voice coil carrier made of polyimide
– Tweeter with 25 mm fabric dome, ferrofluid-cooled neodymium drive, voice coil carrier made of polyimide, including mounting adapters
– Compact 6 dB/Oct. Inline crossover, treble level adjustable in two levels (0/- 3 dB) on the crossover
– Scope of delivery: 2 x bass/midrange speakers, 2 x bass/midrange speaker covers, 2 x tweeters, 2 x inline tweeter crossovers, 2 x tweeter installation housings each, mounting accessories

TECHNICAL DATA
– Rated power rating: 100 watts RMS
– Frequency response: 60Hz – 25kHz
– Impedance: 4 ohms
– Sensitivity: 92dB
– Installation ø: 184 mm, installation depth: 57 mm
