TRF VL SW122 D2

                                               MODEL:TRF VL SW122 D2
SIZE: 12inch
CONE:competition grade paper
SURROUND MATERIAL:foam
VOICE COIL:2 inch
RMS POWER:250 WATT
SENSITIVITY:89db
MAX WATT:500wmaxx
RESORANCE FREQUENCY(fo):36.6Hz
MECHANICAL Q FACTOR(Qms):2.83
ELECTRICAL Q FACTOR(Qes):0.7
TOTAL Q FACTOR(Qts):0.59
X MAX:9 mm
FORCE FACTOR:12.1N/A
MAGNET WEIGHT:40 oz

1=Outer Dimension:315mm
2=Mounting Depth:140mm
3=Magnet Dimension:140mm
4=Mounting Hole Dimension:284mm
