TRF L SW158D2

SPECIFICATION:MODEL:TRF LSW158D2
Size: 15
Cone: Competition  Grade Paper
Surround material: Foam
Voice coil: 3.0inch
Voice coil layer: 4layer
Nominal impedance:dual 2ohm
Voice coil wire:Copper
RMS Power: 800wrms
MAX Watt:1600wmax
Sensitivity: 88.7dB
Resonance frequency(f0): 34.3Hz
Mechanical Q factor(Qms): 5.81
Electrical Q factor:(Qes):0.72
Total Q factor:(Qts): 0.64
Xmax: 15mm
Force factor: 19.7N/A
Magnet Weight: 110 Oz

1=Outer Dimension:  393mm – 15.47″
2=Mounting Depth: 185mm – 7.28″
3=Magnet Dimension: 176mm – 6.90″
4=Mounting Hole Dimension: 350mm-13.78″
