SD8000.1 EVO 5

The 8000.1 EVO 5 is a compact and modern amplifier that delivers 8000W RMS of power in 1 channel.

Incorporated with the innovative MCPCB board. Increasing your efficiency and ensuring much more consistent performance.

• https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

  8000.1 EVO 5 – 1 OHM

  Power @ 4Ω: 1 X 3844 WRMS
  Power @ 2Ω: 1 X 5360 WRMS
  Power @ 1Ω: 1 X8000 WRMS

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

    8000.1 EVO 5 – 1 OHM

    Power @ 4Ω: 1 X 3844 WRMS
    Power @ 2Ω: 1 X 5360 WRMS
    Power @ 1Ω: 1 X 8000 WRMS

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

    8000.1 EVO 5 – 2 OHMS

    Power @ 4Ω: 1 X 5360 WRMS
    Power @ 2Ω: 1 X 8000 WRMS
    Power @ 1Ω: N/A

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

    Frequency Response (-3dB):

    8Hz ~ 20kHz

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

    Subsonic (12dB/oct):

    8Hz ~ 80Hz

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

    Low Pass filter (12dB/oct):

    50Hz ~ 20kHz

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

    Bass Boost:

    0dB ~ 12dB @ 50Hz

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

    Operating Voltage:

    9V ~ 16V

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

    SNR

    @ 1Ω: 92dB
    @ 2Ω: 85dB

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

    Input Sensitivity (RCA):

    0.2V ~ 2V

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

    Input Sensitivity (High Level input):

    1.3V ~ 15V

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

    Current Draw (music):

    381A

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

    Current Draw (max.)

    762A

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

    Total Efficiency:

    80%

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

    Damping Factor (@100Hz nominal impedance)

    >10000

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

    Power Cable:

    70mm² (00 AWG)

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

    Speaker Cable

    2 x 10mm² (7 AWG)

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

    Recommended Fuse (music):

    2 x 200A

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

    Recommended battery (minimum):

    2 x 220Ah

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

    Width:

    7.1″ / 18 cm

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

    Length:

    12.2″ / 31 cm

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

    Height:

    2.5″ / 6.32 cm

  • https://soundigital.com/en/wp-content/uploads/2022/03/hd.jpg’) repeat;”>

    Weight:

    8.79 lb / 3.99 kg
