GZNW 15X-D2

2500 Watts SPL

15″ long excursion subwoofer with aluminum cone

• 15″ long excursion subwoofer
• Klippel® optimized
• Aluminum Cone & dust cap
• High-roll surround
• Solid, blue aluminum cast basket
• 75 mm / 3″ copper round wire voice coil
• 4-layer polycotton spider

• Model	Long excursion Subwoofer
  Diameter	38 cm / 15″
  Power handling (RMS/SPL)	2500 / 4000 Watts
  Impedance	2x 2 Ohms
  Efficiency	85 dB
  Power recommendation	2000 – 3000 Watts
  Voice coil	75 mm / 3″ copper
  Cone	Aluminum
  Max. Excursion (Xmax)	62 mm / 2.44″
  Mounting Ø	360 mm / 14.1″
  Mounting depth	250 mm / 9.84″
  Resonance frequency (Fs)	35.2 Hz
  Damping ratio (Qts)	0.54
  Equiv. air volume (Vas)	28 L / 0.99 cu.ft.
